5000 Series
3300XL B
by Cadman
Hard Hose Traveller
OVERVIEW
The Cadman 3300XL B is built for efficiency and durability on long irrigation runs with dependable coverage across varied crops and field layouts.
Featuring a Honda OHV 5.5 HP engine and Cadman transmission (10-year warranty), it delivers set-and-forget operation with an oversized drum, positive traction chain drive, and built-in safety systems.
PRODUCT DETAILS
Technical Specification
Hose Diameter
3.3″ (84 mm)
Hose Length
2350′ (717 m)
Flow Rate
200–300 GPM (757–1135 L/min)
Input Pressure Range
130–150 PSI (9–10 bar)
Sprinkler Pressure
80–90 PSI (5.5–6 bar)
Drive System
Honda OHV 5.5 HP engine + Cadman transmission (10-year warranty)
Control System
Auto-stop + hose mis-wrap safety shutoff + accurate hose indexing + speedometer
Frame Construction
Oversized heavy-duty drum + positive traction chain drive + slewing ring turntable + lubricated nylon drum bearings + heavy-duty crank-down stabilizers
Approximate Weight
15400 lbs
OPTIONAL FEATURES
Configuration options
Ask about available configurations and options for your operation.
CUSTOM CONFIGURATION- Chain-style stabilizer jacks
- Hydraulic stabilizers (tractor-controlled)
- Quick hitch & tractor lift bar
- Traveller-mounted sprinkler kit
- 4″ blowout adapter with ¼″ inlet
- Gauge protector kit
- Murphy shutdown gauge
